DFMZ's custom Bonnet design provides protection for automated and complex biomedical testing products such as liquid handlers. DFMZ offers positive and negative pressure bonnets with standard or custom shapes and sizes. They are designed to be integrated with your equipment.

* Available in Aluminium.

DFMZ’s seam welded white polypropylene construction features chemical and corrosion resistance.

36” T5 LED light fixtures

HEPA filters rated 99.99% efficient on 0.3μ with pleated MERV 8 pre-filters

HEPA fan filter module to provide up to 350 CFM of HEPA filtered supply/exhaust air

4” Digital Touchscreen HMI for Monitor and Control of Fans, Alarm and Lights.

Light and fan switch with remote for easy on/off operation

Resources

UV Light

Aluminum Build

Double Hepa

Bag in-Bag out

Resources

Product protection - Unidirectional Flow Clean Air Hood

Bonnets (Positive Pressure)

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015

Supply HEPA filters rated 99.99% efficient on 0.3 microns

Exhaust HEPA filters rated 99.99% efficient on 0.3 microns

Designed and manufactured in accrdance with ASHRAE 110 test standards

NSF/ANSI 49 approved and listed

Bonnets (negative pressure)

Personnel and environmental protection - Class I biosafety cabinet (BSC) only suitable for low-level Biosafety Level (BSL-1, 2 or 3) containment.

ESAFE tested and labeled for electrical (CSA and ULC equivalent)
