Product Categories / Laminar Flow Hoods

The DFMZ LHV Series Vertical Laminar Flow Hoods create the ideal environment for processes that require excellent product protection. The downward vertical airflow blankets the work surface with HEPA-filtered clean air (ISO 5 conditions) while maintaining positive pressure within the work zone. The all welded polypropylene construction of the LHV Series Hoods offer excellent resistance to many acids and other chemicals as well as being suitable for metal-free and low level trace analysis applications.

Available Models:
Model LHV-3 Nominal 3ft. wide, Bench-top model
Model LHV-4 Nominal 4ft. wide, Bench-top model
Model LHV-5 Nominal 5ft. wide, Bench-top model
Model LHV-6 Nominal 6ft. wide, Bench-top model

Provides better than ISO 5 conditions

HEPA filter rated 99.99% efficient at 0.3 microns

LED light fixture complete with ON/OFF switch

Constructed from corrosion resistant seam welded
white polypropylene

Fan motors motors complete with ON/OFF switch

Laminar airflow across filter face

Minihelic gauge monitors loading on HEPA filter

Clear acrylic inserts on side panels for additional viewing

Base stands, polypropylene or welded steel construction-fixed heights for 30" or 36" high work surface

Electric hydraulic adjustable base stand kit for work surface height range between 29" and 39" high with universal casters and leveling feet

Vertical sliding clear acrylic faceshield, fully counterbalanced with 10" or 12" high sash opening

Stainless steel IV bar with hooks

Germicidal UV light (stainless steel interior recommended)

Stainless steel back and side panels in lieu of polypropylene

Stainless steel work surface-flat profile in lieu of polypropylene

GFI duplex electrical outlets mounted in side or rear panels

Service fixtures (GAS, AIR, or VACUUM) mounted in side panels

Metal-free construction

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

Vertical Polypropylene Hoods (LHV Series)

HEPA filters rated 99.99% efficient on 0.3 microns

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015

Resources

The DFMZ LHH Series Horizontal Laminar Flow Hoods create the ideal environment for processes that require excellent product protection. The outward horizontal airflow cascades across the work surface providing HEPA-filtered clean air (ISO 5 conditions) while maintaining positive pressure within the work zone. The all welded polypropylene construction of the LHH Series Hoods offer excellent resistance to many acids and other chemicals as well as being suitable for metal-free and low level trace analysis applications.

Available Models:
Model LHH-3 Nominal 3ft. wide, Bench-top model
Model LHH-4 Nominal 4ft. wide, Bench-top model
Model LHH-5 Nominal 5ft. wide, Bench-top model
Model LHH-6 Nominal 6ft. wide, Bench-top model

Provides better than ISO 5 conditions

HEPA filter rated 99.99% efficient at 0.3 microns

LED light fixture complete with ON/OFF switch

Constructed from corrosion resistant seam welded white polypropylene

Fan motors motors complete with ON/OFF switch

Laminar airflow across filter face

Minihelic gauge monitors loading on HEPA filter

Clear acrylic inserts on side panels for additional viewing

Base stands, polypropylene or welded steel construction-fixed heights for 30" or 36" high work surface

Electric hydraulic adjustable base stand kit for work surface height range between 29" and 39" high with universal casters and leveling feet

Germicidal UV light (stainless steel interior recommended)

Stainless steel side panels in lieu of polypropylene

Stainless steel work surface-flat profile in lieu of polypropylene

GFI duplex electrical outlets mounted in side panels

Service fixtures (GAS, AIR, or VACUUM) mounted in side panels

Metal-free construction

Stainless steel IV bar with hooks

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

Horizontal Polypropylene Hoods (LHH Series)

HEPA filters rated 99.99% efficient on 0.3 microns

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015

Resources

The VBM Series Vertical Laminar Flow Hood is a compact, portable laminar flow hood providing the ideal environment for excellent product protection, where particulates are not harmful to the operator. The downward vertical air flow blankets the work surface with HEPA filtered clean air, and maintains a positive pressure environment within the work zone, keeping your products and processes safe from airborne contaminates. A timer for the UV light and window sash interlock features make it an ideal solution for PCR type work.

Available Models: Model VBM-200 Nominal 2 ft. wide Bench-top model

Robust cold-rolled steel construction for exterior shell with durable, anti-microbial powder coat paint finish

High Efficiency Particulate Air (HEPA) filter rated 99.99% efficient at 0.3 microns

Partial recirculation feature to reduce turbulent airflow at the rear of the work zone area

LCD control panel with soft touch switching for lights, fan, airflow speed and UV timer

Laminated safety glass side windows for additional viewing

LED and germicidal UV lighting

Manual vertical sliding faceshield - fully closing

Stainless steel dished work surface

Resources

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

HEPA filters rated 99.99% efficient on 0.3 microns

Compact/Benchtop Hoods (VBM Series)

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015

Resources

The DFMZ VCM Series Vertical Laminar Flow Hoods provide the ideal environment for excellent product protection, where particulates are not harmful to the operator. The downward vertical air flow purges the work area with HEPA filtered clean air (ISO 5), and maintains a positive pressure environment within the work zone, to keep products and processes free from airborne contaminates.

Available Models:
Model VCM-400 Nominal 4 ft. wide, Console model
Model VCM-600 Nominal 4 ft. wide, Console model

Robust cold-rolled steel construction for exterior shell with durable, anti-microbial powder coat paint finish

High Efficiency Particulate Air (HEPA) filter rated 99.99% efficient at 0.3 microns

Disposable, MERV 8 rated pleated pre-filters

Minimum ISO 5 (Class 100) conditions within the work zone

Front mounted control panel with LCD display controls lighting, fans, outlets and monitors airflow velocity as well as HEPA filter loading

Motorized vertical sliding faceshield

Energy efficient LED task lighting

Germicidal UV light with safety interlock to sash and supply fan motors

Manual adjustable height base frame for work surface height range between 29" and 36" high, c/w universal casters and leveling feet

Stainless steel back panel with partial recirculation feature to reduce turbulence at the rear of work zone

Stainless steel work surface with dished profile to contain spills

Two duplex electrical outlets with splash covers on rear wall

Laminated safety glass side windows for additional viewing

Resources

Electric hydraulic adjustable height base frame kit for work surface height range from 29” to 39” high, c/w 8' grounded cord and plug

Stainless steel IV bar, complete with (5) hangers, fixed position

Service fixtures on side panels (GAS, AIR or VACUUM)

Stainless steel side panels in lieu of safety glass inserts

Resources

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

Vertical Metal Hoods (VCM Series)

HEPA filters rated 99.99% efficient on 0.3 microns

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015

Resources

The DFMZ HCM Series Horizontal Laminar Flow Hoods provide the ideal environment for excellent product protection, where
particulates are not harmful to the operator. The outward horizontal air flow purges the work area with HEPA filtered clean air (ISO 5), and maintains a positive pressure environment within the work zone, to keep products and processes free from airborne contaminates.

Available Models:
Model HCM-400 Nominal 4 ft. wide, Console model
Model HCM-600 Nominal 6 ft. wide, Console model

Robust cold-rolled steel construction for exterior shell with durable, anti-microbial powder coat paint finish

High Efficiency Particulate Air (HEPA) filter rated 99.99% efficient

Disposable, MERV 8 rated pleated pre-filters

Minimum ISO 5 (Class 100) conditions within the work zone

Front mounted control panel with LCD display controls lighting, fans, outlets and monitors airflow velocity as well as HEPA filter loading

Motorized vertical sliding faceshield, laminated safety glass construction (fully closing)

Energy efficient LED task lighting

Germicidal UV light with safety interlock to sash and supply fan motors

Manual adjustable height base frame for work surface height range between 29" and 36" high, c/w universal casters and leveling feet

Perforated air diffusion screen in front of HEPA filter to enhance laminar flow

Stainless steel work surface-flat profile

Two duplex electrical outlets with covers on ceiling of work zone

Laminated safety glass side windows for additional viewing

Resources

Electric hydraulic adjustable height base frame kit for work surface height range from 29” to 39” high, c/w 8' grounded cord and plug

Stainless steel IV bar, complete with (5) hangers, fixed position

Service fixtures on side panels (GAS, AIR or VACUUM)

Stainless steel side panels in lieu of safety glass inserts

Resources

ESAFE tested and labeled for electrical (CSA and ULC equivalent)

HEPA filters rated 99.99% efficient on 0.3 microns

Horizontal Metal Hoods (HCM Series)

Provide minimum ISO Class 5 cleanliness conditions as per ISO Standard 14644-1:2015
